The KSM9HS is a premium vocal condenser microphone that captures vocal subtlety with extraordinary detail to deliver clear articulation, functional flexibility, and precise vocal reproduction for live performance.
Engineered to exacting standards, the KSM9HS reveals nuance and subtlety in a microphone optimized for the most demanding live environments. With its dual diaphragm design and switchable polar patterns (hypercardioid / subcardioid), the KSM9HS is the choice for the world's most accomplished vocal performances.
KSM9HS microphones offer exceptional consistency across all frequencies, providing more gain before feedback, while decreasing proximity effect. As the premier choice in handheld wireless microphone options for Axient®, UHF-R®, and ULX-D™, KSM9HS microphones are built to exacting Shure endurance standards, renowned worldwide and proven night after night, center stage.
Cartridge Type : Condenser (Electret Biased)
Frequency Response : 50 Hz to 20 kHz
Polar Pattern : Hypercardioid, Subcardioid (selectable)
Output Impedance : 145 Ohms
Sensitivity : At 1 kHz (typical):
Hypercardioid : -50.5 dBV/Pa (2.99 mV)
Subcardioid : -53.0 dBV/Pa (2.24 mV)
Maximum SPL : 1 kHz at 1% THD:
Hypercardioid:
Subcardioid:
153.0 dB, 2500 Ohm load
153.1 dB, 1000 Ohm load
Signal to Noise Ratio : Hypercardioid : 73.3 dB
Subcardioid : 71.3 dB
Dynamic Range : 1 kHz at 1% THD:
Hypercardioid:
130.8 dB, 2500 Ohm load
130.1 dB, 1000 Ohm load
Subcardioid:
131.3 dB, 2500 Ohm load
130.6 dB, 1000 Ohm load
Common Mode Rejection : 20 Hz to 8 kHz ≥ 60 dB
Phantom Power : 48 ± 4 VDC (IEC-268-15/DIN 45 596), positive pins 2 and 3
Current Drain : 5.2 mA typical at 48 VDC
Self Noise : Equivalent SPL, A-weighted (typical):
Hypercardioid: 20.7 dB
Subcardioid: 22.7 dB
Clipping Level : 20 Hz to 20 kHz:
7.0 dBV, 2500 Ohm load
6.4 dBV, 1000 Ohm load
Polarity : Positive pressure on front diaphragm produces
Positive voltage on output pin 2 relative to pin 3
Power Requirements : 11 to 52 VDC phantom power (IEC-61938), 5.4 mA, typical
Connector : 1x 3-pin XLR male, balanced
Weight : 10.6 oz (300 g)
