Behringer 904A Voltage Controlled Low Pass Filter Eurorack Module

Behringer 904A VCF is a self-oscillating resonant lowpass filter brimming with thick and gritty vintage character. The 904A’s two primary controls Fixed Control Voltage and Regeneration carry the names found on the original unit, but, in modern parlance, they translate to filter cutoff and resonance, respectively. And they behave exactly as you would expect, with the unmistakable sound that has cemented its place in synthesis history. A Frequency Range knob lets you select from three frequency cutoff bands: position one spans from 1HZ to 5kHz, position 2 is 4Hz to 20kHz, and position 3 is 16Hz to 80kHz, so you have ample control over your filter sweeps. The 904A is equipped with a signal input and output. It also includes three CV control inputs for manipulating the Fixed Control Voltage, which are summed for creating dynamic movements from multiple LFOs or other modulation sources. Synthesists at Music Bliss couldn’t be more excited about the spot-on re-creations found in Behringer’s System 55 modules, including the 904A VCF. And, with their comfortable price point, they’re a great way for the Eurorack-curious to enter the world of modular synthesis and for advanced Eurorack users to expand their existing systems.

FEATURES

• Vintage-sounding 904A Low Pass VCF module from the '70s
• Authentic reproduction of the circuitry from the "Modular 55, 35 & 15" Series
• Artist roster includes world's most famous pop, rock and jazz musicians
• VCF features Fixed Control Voltage (Cutoff), Range and Regeneration (Resonance) controls
• Audio in and out connectors plus 3 CV inputs for control of frequency
• 2 controls and a switch gives you real-time access to all important parameters
• Eurorack specs: 8 HP, 65 mA +12 V, 50 mA -12 V

SPECIFICATIONS

• Type : Low Pass VCF Eurorack Module
• Depth : 1.6" (40mm)
• HP Size : 8HP
• Power Usage : +12V/65mA, -12V/50mA
• Power Supply : Requires Eurorack case and power supply
