JBL Intonato 24 Monitor Management Tuning System (Intonato24)

Engineering isn't constrained to purpose-built production spaces. Small rooms are taking on final mixes, stereo rooms are stepping up to surround, and object-based audio is becoming the norm for post-production studios. That's why you need the JBL Intonato 24. It accommodates up to 24 speakers. It tackles stereo, surround, and immersive audio with ease. Best of all, you can analyze and calibrate each speaker's response for absolute accuracy. Enjoy customized routing of up to 24 analog, digital, and networked audio sources. Take comprehensive control of your monitoring via Mac, PC, or tablet. With an Intonato 24 in your rack, you'll benefit from an ideal monitoring environment wherever you go.

VIDEO

FEATURES

• Monitor controller that accommodates up to 24 speakers
• Automated Speaker Calibration allows you to achieve top-notch mixes in any acoustic environment (measurement microphone is included)
• Enough I/O to tackle stereo, surround, and immersive audio projects with ease
• Subwoofer integration with selectable crossover settings for LFE channels
• Flexible patching, routing, and monitoring of up to 24 analog, digital, and networked audio sources
• Store and recall custom user profiles to adapt to different projects and workflows
• Software-controlled analog input sensitivity switches, level indicators, and gain trims
• Volume, Mute, and Dim controls, plus individual speaker Mute and Solo
• Per-speaker, 8-band User EQ allows standard and customized response curves and compensation for perforated screen transmission loss
• Variable Audio/Video Sync delay compensates for video display latency
• Stereo Aux Out with level control, EQ, and talkback system allows an independent feed to be sent to talent
• Networks to Crown power amplifiers and a vast array of other JBL system components
• Optional Intonato Desktop Controller (sold separately) supplies complete control over system volume, recall of user-configured scenes, activation of speaker mutes and solos, and other frequently used features
• FREE downloadable software provides comprehensive control of your monitoring via Mac, PC, or tablet
• Low-noise fan for whisper-quiet operation
• Housed in a 2U rackmountable enclosure

SPECIFICATIONS

• Input Channels:Up to 24 speakers
• Output Channels:24
• Analog Inputs:3 x DB-25 (groups A, B, C), 1 x XLR (mic)
• Analog Outputs:3 x DB-25 (groups A, B, C)
• Digital Inputs:3 x DB-25 (AES)
• USB:1 x Type B
• Other I/O:1 x Ethernet (DHCP network), 2 x RJ45 (BLU link)
• Word Clock:In
• Software:Intonato Control app
• Compatibility:Mac, Windows, iOS, Android
• Form Factor:2U Rackmount
• Height:3.5"
• Width:19"
• Depth:13.75"
• Weight:14.3 lbs.
