PreSonus StudioLive 32R 32 Channel Rackmount Digital Mixer

PreSonus StudioLive 32R 32 Channel Rackmount Digital Mixer

The PreSonus StudioLive 32R exhibits exceptional performance, both as a rackmount mixer and as a stagebox for your StudioLive Series III console. It features 32 great-sounding XMAX preamps, a flexible array of I/O, and comprehensive routing, making it useful in innumerable live applications. It's equally at home in the studio, boasting built-in 40-in/40-out USB and 55-in/55-out AVB audio interfaces. Onboard stereo SD recording is also supported, making instant live recordings a breeze. Sculpt your sound to perfection, thanks to vintage-style EQ and compression on every channel, along with a range of reverbs and delays. The StudioLive 32R comes complete with wireless control via your computer or smart device.

FEATURES

• 34-input, 32-channel digital rackmount mixer and AVB Stagebox for StudioLive Series III consoles
• Record and play back up to 40 channels via USB, or up to 55 channels via AVB Ethernet
• Integrated stereo SD digital recorder is perfect for instant live recordings
• 32 fully recallable XMAX preamps with ultra-low noise floor
• 4 internal effects buses with a combination of reverbs, delays and other effects
• Fat Channel processing provides vintage EQ and compression options for each channel
• Advanced scene management helps you manage complex mixing tasks more efficiently
• 16 Flex Mixes can be used as Aux mixes, Subgroups, or Matrix mixes
• Software package includes UC Surface 2 touch-control software (Mac/PC/iOS), Capture recording software (Mac/PC), Studio One Artist DAW software (Mac/PC), QMix personal monitoring app (iOS/Android)

SPECIFICATIONS

• Type:Rackmount Digital Mixer
• Channels:40 x 40 (USB), 55 x 55 (AVB networking)
• Inputs - Mic Preamps:32 x XLR-1/4" combo (mic/line)
• Phantom Power:Yes
• Inputs - Other:1 x Dual RCA Stereo
• Outputs - Main:2 x XLR
• Outputs - Direct:16 x 1/4" (mix out)
• Data I/O:1 x EtherCon (AVB), 1 x RJ-45 (network control)
• USB:1 x Type B
• Computer Connectivity:USB (40 x 40), Ethernet (AVB, 55 x 55)
• Headphones:1 x 1/4" TRS
• EQ Bands:4-band/6-band Parametric EQ, 31-band Graphic EQ
• Effects:Studio Magic Plug-in Suite
• Signal Processing:Gate, Compressor, Limiter
• Features:Onboard stereo SD recorder
• Software:Studio One Artist, UC Surface Touch, Capture, QMix-UC
• OS Requirements - Mac:OS X 10.8.5 64-bit or later, Intel Core i3 or higher
• OS Requirements - PC:Windows 7 SP1 64-bit or later, Intel Core i3 or higher
• Rackmountable:Yes
• Power Source:Standard IEC AC cable
• Height:3.5"
• Depth:12"
• Width:19"
• Weight:11.2 lbs.
