Audiocenter MA12+ Portable Active DSP-controlled Loudspeaker

The MA12+ is crafted from a newly developed polypropylene composite material, custom molded to deliver a stylish appearance, superior performance, and lightweight usability. Integrated with BrainCore™ technology, the MA12+ achieves high integration of the input signal, power amplifier, and DSP module. This optimizes audio energy for maximum efficiency, ensuring the product is both stable and reliable. Equipped with Bluetooth and TWS (True Wireless Stereo) technology, the MA12+ enables convenient stereo wireless pairing, allowing users to enjoy stable, high - quality sound anytime, anywhere. The MA12+ can be mounted on a tripod or suspended for use as a main PA speaker and is also suitable for stage monitoring.

SPECIFICATIONS

• Frequency Response(-10dB) : 50Hz-20kHz

• Horizontal Coverage : 90°

• Vertical Coverage : 60°

• Maximum Calculated : 125dB/131dB
  SPL/1M(Continuous/Peak)

• HF Driver : Customized driver,1.75” voice coil, 1.0” exit

• LF Driver : Customized 12” driver, 2.5” voice coil

• Processor : 48kHz signal sampling frequency

• Presets : MUSIC，FLAT，SPEECH，W/SUB
  AMPLIFIER

• Amplifier Circuitry : Class D

• Power (RMS standards) : 800W

• Peak Power : 1600W

• Frequency Response : 20Hz-20kHz(±0.5dB)
  (1W 8Ω 2ch)

• Intermodulation Distortion : <0.05%

• Total Harmonic Distortion : <0.05%

• Signal Input : Female XLR(Mono jack 6.35), 3.5mm Jack Input, Wireless bluetooth

• Signal Output : Male XLR mixed output or balanced output

• Power Input : IEC power connector

• AC Power Operating Range : 100-240V~ (±10%,50/60Hz）

• Power consumption  : 55W
