Blackmagic Design ATEM Television Studio HD8 2TB 8-channel HD Video Switcher

Live production video switching in locations of all sizes is made simpler with the all-in-one Blackmagic Design ATEM Television Studio HD8 2TB compact switcher and control panel. A total of eight standards-converted 3G-SDI inputs and outputs with embedded audio capture deliver stunning camera quality, while four chroma keyers, SuperSourcing, media players, and more back up your footage with a professional-grade visual sheen. This model adds 2TB of internal M.2 flash storage for internal recording and acts as a network disk when connected via Ethernet. Its intuitive array of buttons enables comprehensive previewing, transitioning, audio processing, and beyond, keeping all of your controls at hand. Endless effects and organizational features make the HD8 2TB a Music Bliss favorite, especially for its real-time DVE scaling and ability to resize multiple feeds. And the included ATEM Software Control unlocks remote access to the onboard Fairlight audio mixer, providing additional equalization and compression capabilities to balance the right audio signal every time. Compact and capable, the Blackmagic Design HD8 2TB is sure to take your TV studio-scale production to the next level.

FEATURES

• Live production compact video switcher and control panel with 2TB of internal storage

• 8 embedded audio 3G-SDI I/O for up to 8 video cameras

• 2 x 3G-SDI aux outputs connect projectors and presenting monitors

• SDI and HDMI/SDI Multiview connections allow for multi-source monitoring

• Main SDI Program Outfit simplifies the recording and transmission of video feeds

• Audio connections include control room and studio speaker I/O, talkback/headset, hi-fi stereo, and balanced XLR analog audio

• Talkback expansion port is compatible with Clear-Com and RTS systems

• 4-port Ethernet bank for computer-/internet-based connections

• Microphone expansion availability with MADI audio ports

• Easily time-code with dedicated I/O

• 2 USB-C jacks allow for flash disk recording and mobile phone streaming

• Broadcast system sync-ability with classic 4-pin 12V DC power and standard IEC 100-240V AC power connections

• Large status display screen with nearby master settings controls

• Numeric keypad allows for parameter entering for transition duration adjustments, etc.

• Audio control module powered by onboard Fairlight mixer with EQ, compression, limiting, expanding, noise gating, panning, and AFV

• Bus selections set inputs to processing for keyers and DVEs

• Preview/Program buttons let you view feeds and transitions before airing them

• Transition controls with large T-bar fader to automatically and manually manipulate transition speed, respectively

• Dedicated grid controls for green screen keys and graphic cueing
  Fade-to-black switch ends program feeds with a classic fade
• Support for internal media, including 20 HD stills, 400-frame 720HD/200-frame 1080HD motion graphics

• 4 chroma keyers with background generation, color matching, and more

• SuperSourcing integrates up to 4 additional live video layers for interviews, as well as multiview games and events

• Hardware streaming engine reaches a global audience on popular platforms like YouTube, Facebook, and Twitch via Ethernet or 5G smartphones

SPECIFICATIONS

• Model : ATEM Television Studio HD8 2TB

• Type : HD Live Production Video Switcher

• Channels : 8 x Video Inputs, 12 x Video Outputs

• Video Format : Up to 1080/60fps

• Video Inputs : 8 x BNC (3G-SDI)

• Video Outputs : 8 x BNC (3G-SDI aux), 3 x BNC (3G-SDI aux/program), 1 x HDMI (multi-view), 1 x BNC (SDI multi-view)

• Audio Inputs : 2 x XLR, 1 x Dual RCA Stereo
  Audio Outputs : 4 x 1/4"

• Sync : 2 x BNC (ref in, out), 2 x BNC (timecode in, out), 2 x BNC (MADI in, out)
  Headphones : 1 x 5-pin XLR (rear, talkback)

• USB : 2 x USB-C

• Other I/O : 4 x RJ-45 (10G ethernet), 1 x RJ-45 (external talkback), 1 x RJ-12 (RS-422)

• Software : ATEM Software Control Panel (mac/windows)

• Features : Built-in 2TB Internal Storage, Transition Lever, LCD Display, & 2 x Media Players

• Power Source : Standard IEC AC Input, 4-pin XLR DC Input

• Height : 6.38"

• Width : 23"

• Depth : 14.8"

• Weight : 14.9 lbs
