Bose Panaray MSA12X Digital Beam-Steering Loudspeaker - Black

The Bose Professional Panaray MSA12X is a self-powered digital beam-steering loudspeaker that enables improved room aesthetics, with outstanding vocal intelligibility and tonal consistency. The proprietary Articulated Array transducer configuration allows wide, 160° horizontal coverage throughout the room, and MSA12X’s modular design allows building of vertical arrays using 1-3 units. Dante digital audio network interface comes standard for connection with other Dante-enabled products over Ethernet-based networks.

FEATURES

• Digital beam-steering line array column loudspeaker with onboard DSP and 600 watts (12 x 50 W) of amplification
• Family sound profile with the Panaray MA12EX Loudspeaker
• Twelve (12) x 2.25-inch full-range transducers with 58 Hz – 18 kHz frequency range
• Dante® digital audio network interface and line-level analog input
• Articulated Array® configuration allows wide, 160° horizontal coverage
• Modular design allows building vertical arrays using 1-3 units
• Multiple algorithms for beam steering control – designers can optimize consistency of coverage, tonal balance, and maximum SPL per job
• Supports independent level and EQ control of 2 separate beams per array
• Integrated mounting bracket allows up 90° of horizontal yaw adjustment
• Advanced steering and acoustic coverage prediction using Bose Modeler® software
• System setup, control and monitoring with Bose ControlSpace® Designer™ software
• Available in black or white finish

SPECIFICATIONS

• Frequency Range (-10 dB) : 58 Hz – 18 kHz
• Horizontal Dispersion : 160° H
• Vertical Opening Angles : Software Adjustable: 1 module: up to 30°, 2-3 modules: up to 40°
• Vertical Beam Steering Angles : + / - 20°
• Driver Compliment : Twelve (12) x 2.25-inch full-range transducers
• Amplifier Power Handling : 600 W (12 x 50 W)
• Maximum SPL @ 1 m : 112 dB SPL (118 dB SPL peak)
• Inputs : Dante® digital audio network interface and line-level analog input
