Flock Audio CX 8-channel Hardware Input Module

Music-makers who use Flock Audio Patch Series equipment will love using the company’s CX 8-channel input module. This exciting new piece of gear allows you to route any type of analog audio signal from the input through a Patch series patchbay for the cleanest, most transparent routing experience. Like the Patch Series, the CX also features a 100% analog signal path with no latency and no AD/DA conversion. The front panel features eight XLR/TRS combo jack inputs. Each input boasts individually assignable phantom power, which helps the CX handle any combination of mic- and instrument-level sources. The rear panel houses an 8-channel DB-25 connector for attaching the CX to your Flock Audio Patch Series patchbay. You can also use the CX as a standalone preamp to cleanly boost your source by up to 60dB. Finally, the Flock Audio CX 8-channel Hardware Module is controlled and customized via either the Flock Audio Patch App or the Patch App DX. Add the CX input module to your Patch Series setup and enjoy squeaky-clean audio right from the source.

FEATURES

• 8 channels of analog hardware I/O for implementation with Flock Audio Patch Series patchbays

• 100% transparent analog signals with no latency or AD/DA conversion

• 8 XLR/TRS combo jack inputs for mic-/instrument-level signals, each with independent phantom power switches

• 8 channels of output via D-SUB for connection to Patch Series patchbays

• Can be used as a desktop module or as a rackmount module by using the included rack ears

• Controllable via Flock Audio Patch App or Patch App DX

SPECIFICATIONS

• Type : 8-channel Preamp Expansion

• Channels : 8

• Inputs : 8 x XLR-1/4" Combo

• Outputs : 1 x DB-25

• Digital Inputs : 1 x USB-B (host control)

• Features : Flock Audio PATCH Series

• Power Supply : Locking External Power Supply (included)

• Height : 1.75"

• Width : 10.25"

• Depth : 7"

• Weight : 5 lbs.
