Lab Gruppen CPA2402 8-Input Commercial Mixer Amplifier with Bluetooth and USB Media Player

CPA2402 is easy to install and operate – even for non-technical personnel. Simply put, the CPA2402 is ideal-suited for bars & restaurants, retail destinations, hotels, corporate, education or other venues needing background music and/or a public address system. 2 x 240 Watt Commercial Mixer Amplifier provides the perfect solution for commercial and industrial applications requiring great sounding distributed audio coupled with power conservation and reduced operating expense. Capable of delivering high-quality sound over both Low-Z (4/8 Ohm) and High-Z (70/100 V) loudspeaker configurations offering extreme flexibility on every channel.

FEATURES

• 2 x 240 Watt mixer amplifier for commercial and industrial applications
• Low-Z (4/8 Ohm) and High-Z (70/100 V) operation per output with switchable high-pass filter
• 6 mic/line inputs plus 2 line inputs each with individual volume controls and output routing
• High-quality media playback via Bluetooth streaming
• USB media player with intuitive LCD navigation to play audio files via USB stick
• Individual front panel master volume and bass/treble controls for each output
• Configurable priority and chime muting function for background music override
• Direct drive, constant power technology for superior audio performance and reliability
• GPI remote volume control using standard RJ-45 connector and Ethernet cable
• Auto Ramp circuitry for quiet and fast power up/down enables real-world energy savings
• Front panel power control button for direct access
• Aux outputs for expansion to additional amplifiers
• Rack-mountable 1U, 19" enclosure with brackets for rack mounting
• Euroblock type mic/line input and output connectors
• Convection-cooled, fan-less amplifier technology for low noise

SPECIFICATIONS

• Maximum Output Power : 4 or 8 Ω per channel : 240 W

• Number of Amplifier Channels : Number : 2

• Minimun Load Impedance
  - 4 Ω mode : 4 Ω
  - 8 Ω mode : 8 Ω
  - 70 V output mode : 20 Ω
  - 100 V output mode : 42 Ω

• Audio Outputs
  - Amplifier output : 4-pin Euroblock connector
  - Aux output : 2 x 3-pin Euroblock connector
  - Aux output max level : 4.88 V (16 dBu)

• Audio Inputs
  - Mic/Line with priority/ ducking input : 2 x 5-pin Euroblock connector (channel A, E)
  - Mic/Line with summed RCA : 4 x 3-pin Euroblock connector, 6 x stereo RCA
  - Impedance : Balanced mic/line: 20 kΩ | Unbalanced line and RCA : 10 kΩ
  - Input sensitivity for max amplifier output or max aux output level : Mic: 0.038 V (-26 dBu) | Balanced: 1.23 V (+4 dBu) | RCA: 0.62 V (-2 dBu) each for mono sum RCA

• Maximum input level : 4.88 V (+16 dBu)

• Microphone phantom voltage : 48 V

• Tone Controls
  - Bass : ±10 dB @ 100 Hz
  - Treble : ±10 dB @ 10 kHz

• Indicators
  - Power : On (blue), force standby (red), standby (yellow)
  - Inputs : Signal (green LED): >12.3 mV (-36 dBu) | Fault (red LED): Clip
  - Master : Signal (green LED): >-50 dBu | Fault (red LED): Overheat, DC fault, over current, etc

• Bluetooth
  - Frequency range : 2402 - 2480 MHz
  - Channel number : 79
  - Bluetooth version : 4.2
  - Reception range : Up to 15 m (45 ft)
  - Output power : 10 dBm
  - Supported codec : SBC
  - Supported profiles : AVRCP 1.4, A2DP 1.2

• USB Drive Requirements
  - Type : USB 2.0
  - Min capacity : 1.0 GB
  - Min speed : 12 MB/s read, 7 MB/s write
  - Supported file formats : AAC, WMA, MP3, WAV

• Performance
  - Distortion, 1/8 rated power : <0.5%
  - Frequency response : 20 Hz to 20 kHz, +0.5/-2 dB
  - Crosstalk (2 channel models) : >70 dB
  - Signal-to-noise : >95 dB
  - High-pass filter : 80 Hz HPF

• Power Supply, Voltage (Fuse)
  - Main voltage : 100-240 V~, 50/60 Hz with active power factor correction
  - Fuse : T 10 A H 250 V
  - Power consumption 1/8th rated power @ 4 Ω : 140 W
  - Mains connector : Standard IEC connector

• Dimensions (H x W x D) : 44 x 437 x 248 mm (1.7 x 17.2 x 9.8")

• Weight : 3.6 kg (7.9 lbs)
