Mooer GE1000 Guitar Amp Modelling and Multi Effects Pedal with Touch Screen - White (GE-1000)

The Mooer GE1000 is a Walking Star-designed multi-effects unit with an intuitive 5-inch color touchscreen.
It includes over 350 effects, including over 100 amp models, over 10 power amp models, and over 80 cabinet models. It features an individually configurable effects loop.
Effect modules can be duplicated (depending on DSP power). The connection order of effect modules can be freely changed.
Up to 255 of these settings can be saved as presets.

Various settings can be operated via the touchscreen, allowing for intuitive effect control. Additionally, the GE series' signature physical effect block buttons allow for quick effect on/off and setting adjustments. It

offers a highly flexible signal path with two inputs, two outputs, an effects loop, and internal parallel routing.

The GE1000 also incorporates an innovative AI equalizer that learns your tone based on your musical style and automatically suggests settings that suit your style.

It features an onboard expression pedal and can be further expanded with the Mooer GWF4 wireless footswitch.

In addition to a drum machine looper and tuner, it boasts a variety of functions including Bluetooth audio playback, MIDI control, and a USB audio interface.

FEATURES

• Walking Star design for the Mooer GE series
• Traditional version (GE1000) and version using a 7.4V / 4750mAh lithium-ion battery that can be used without a power cable (GE1000Li)
• Large 5-inch touchscreen for intuitive operation
• 255 preset spaces with 85 storage banks with 3 presets each
• Innovative AI equalization to adjust sound quality according to musical style
• Various I/O options for flexibility in studio, stage, practice, etc.
• Stereo output and parallel/serial stereo effects loop
• Physical effect block buttons unique to the GE series
• Onboard pedal can be used as a volume pedal or expression pedal
• Mooer wireless footswitch expands control options
• Groove Station mode for synchronizing drum machine and looper
• Built-in high-precision tuner
• Tap tempo control of tempo-based effects and drum machine
• Global EQ plus globally adjustable input/output levels to suit various instruments and venues
• Supports Bluetooth audio playback
• Programmable MIDI port for MIDI IN or MIDI OUT
• USB Type-C port
  - low latency, professional ASIO USB audio interface (Type-C) up to 192kHz
  - USB-MIDI functionality
  - firmware updateable via PC software.

SPECIFICATIONS

• Effect
  Module Type: 11
  Effect Models: 350+
  Preset Slots: 255
• Impulse Response
  Format: WAV
  Sampling Rate: 44.1kHz
  Sampling Depth: 24bit
  Sample Points: Up to 2048 sample points
• Input
  INPUT Jack
  Type: 1 x 1/4” Unbalanced Mono
  Input Impedance: 1MOhm
  Maximum Input Level: 10dBu
• RETURN Jack
  Type: 1 x 1/4” Unbalanced Mono
  Input Impedance: 1MOhm
  Maximum Input Level: 10dBu
• Audio AD Converter
  Sampling Rate: 44.1kHz
  Sampling Rate Depth: 24bit
  Dynamic Range: 114dB
  Frequency Response: 20Hz-20kHz, +0/-1dB
• Output OUTPUT
  Jack
  Type: 2 x 1/4” Unbalanced Mono
  Output Impedance: 600Ohm
  Maximum Output Level: 18dBu
• XLR Connector
  Type: 2 x Balanced XLR
  Output Impedance: 600Ohm
  Maximum Output Level: 18dBu
• SEND Jack
  Type: 1 x 1/4” Unbalanced Mono
  Output Impedance: 510 Ohm
  Maximum Output Level: 18 dBu
• PHONES Jack
  Type: 1 x 1/8” Unbalanced Stereo
  Output Impedance: 6 Ohm
  Maximum Output Level: 18 dBu
• Audio DAC
  Dynamic Range: 115 dB
  Frequency Response: 20 Hz-20 kHz, +0/-1 dB
  S/N Ratio: 115 dB
• Other
  MIDI Interface
  MIDI IN or MIDI OUT: 1 x 5-pin female connector
• USB Port
  Type: TYPE-C connector
• USB Audio: USB 2.0, 2 in 2 out, 44.1-192 kHz, 24 bit
  Type: TYPE-C connector
• General
  Power Supply: DC 9V, 1A, Center Negative
  Dimensions: 337 mm × 170 mm × 57 mm (LxWxH)
  Weight: 1.9 kg
  Accessories: Adapter, USB cable, Quick guide
• Type: Multi-effects pedal
  Adapter: 9V center negative
  Battery powered: -
  Controls: MASTER, SELECT, HOME, SAVE, SETTINGS, A, B, C, ▲, ▼, Power, Exp1, Effect Block
