PreSonus StudioLive Series III SE 16 Digital Mixer

When PreSonus launched the first generation of StudioLive mixers in 2009, they were instant hits at Music Bliss and successive generations have only gotten better. Packed with innovations such as motorized faders, great-sounding EQ, smart onboard networking, and seamless DAW integration, these groundbreaking consoles, as their name would imply, have become omnipresent in small studios and live sound environments. Now, PreSonus takes it all to the next level with StudioLive Series III SE, the third generation of the small-format digital mixing powerhouse. Available in 16-, 24-, and 32-input versions, StudioLive Series III SE rocks studio-grade sonics, intuitive one-to-one controls, flexible bus configuration, advanced AoIP implementation, seamlessly integrated recording capabilities, and a suite of premium software starring PreSonus Studio One Pro. And arguably best of all, StudioLive Series III SE delivers this level of performance and versatility for a price any studio or sound reinforcement company can afford.

FEATURES

• Compact, 16-input digital mixer with built-in SD card recorder
• 16 mic/line inputs with recallable XMAX preamps
• 26 mix buses, 10 mix outputs, dedicated Main LR outputs, and Mono sum output
• Integrated 34 x 34 multitrack SD card recording
• 17 fully recallable touch-sensitive motorized faders
• Milan-certified AVB audio networking ecosystem
• 64 x 64 USB 2.0 interface enables high-speed, bidirectional computer connectivity
• 7 State-Space modeled EQs and 8 vintage-style compressor options available on every input and bus
• 16 FlexMixes (aux mixes, subgroups, or Matrix mixes); 4 dedicated FX mixes
• 4 dedicated subgroups and 24 DCA Groups
• Universal Control software lets you remotely control your mixer and dial in mixes offline
• Control your mixer over the internet with real-time monitoring using PreSonus Metro
• Free QMix-UC app for iOS and Android with Wheel of Me artist monitor mixes

SPECIFICATIONS

• Type : Digital Mixer with Recording

• Channels : 40

• Inputs - Mic Preamps : 8 x XLR (mic), 8 x XLR-1/4" Combo (mic/line)

• Phantom Power : 16 Channels

• Inputs - Other : 1 x Dual RCA Stereo (Tape In)

• Outputs - Main : 3 x XLR (Left, Right, Mono)

• Outputs - Direct : 6 x XLR, 4 x 1/4" TRS

• Outputs - Other : 1 x Dual RCA Stereo (Tape Out)

• Outputs - Digital : 1 x XLR (AES), 1 x EtherCON (AVB)

• Send/Return I/O : 2 x 1/4" TRS (Monitor L/R), 4 x 1/4" TRS (Aux)

• Busses/Groups : 4 x Subgroups, 24 x DCA Groups

• Talkback : Yes

• Data I/O : 1 x RJ45 (Control)

• USB : 1 x Type B

• Computer Connectivity : USB (64 x 64)

• Bluetooth : Yes

• Remote : PreSonus Metro

• Faders : 17

• EQ Bands : 4-band

• Effects : Yes

• Signal Processing : Gate, Compressor

• Transport Controls : Yes

• DAW Control : Yes

• Storage : SD card (34 x 34)

• Software : QMix-UC (iOS & Android)

• Power Source : Standard IEC AC Cable

• Height : 6.51"

• Depth : 22.97"

• Width : 17.59"
