Telefunken ELA M 260 Cardioid Stereo Set Small-diaphragm Tube Condenser Microphone

The small diaphragm ELA M 260 has become a staple for use in a multitude of recording applications due to its natural presence and high level of detail and clarity, especially in acoustic and classical applications. Keeping this in mind, TELEFUNKEN Elektroakustik is now offering the Telefunken ELA M 260 Tube Condenser Mic Cardioid Stereo Set. The matched ELA M 260 Cardioid Stereo Set comes in a custom locking flight case that carries both M 860 cables, M 761 shock mounts, microphones, and an American-made dual-channel M 960S power supply unit. This power supply is fully regulated and will power one or both microphones simultaneously, and features a slow-ramping heater voltage to ensure vacuum tube longevity.

The ELA M 260 Stereo Set offers the user the knowledge and comfort that the tools they are using will give identical responses for their most important stereo recording. ELA M 260 Cardioid Stereo Set system packages are supplied with a matched pair of interchangeable, thread-on TK60 Cardioid capsules. Additional TK61 Omnidirectional and TK62 Hypercardioid capsules can be purchased and attached separately. Each stereo microphone system includes a new M 960S dual power supply, (2x) M 860 25’ dual-shielded tube microphone cables with right angle female XLR connectors, (2x) M 761 elastic shock mounts and a locking flight case.

INCLUDED ACCESSORIES

2x Tube Mic Cable, Dual Power Supply, 2x Foam Windscreen, 2x Elastic Shock Mount, Flight Case

SPECIFICATIONS

• LENGTH : 5.5 in
• DIAMETER : 0.8 in
• UNIT WEIGHT : 0.3 lb
• TUBE OR SOLID STATE : Tube
• TUBE TYPE : NOS 5840W vacuum tube
• CAPSULE TYPE : TK60 15 mm edge terminated diaphragm
• TRANSDUCER TYPE : Condenser
• POLAR PATTERN : Cardioid
• NUMBER OF MICROPHONES : Stereo Pair
• IMPEDANCE : 200 ohms (output)
• FREQUENCY RANGE : 20 Hz - 20 kHz ± 3 dB
• SENSITIVITY : -35.7 dBV/Pa (16.5 mV) ± 1 dB
• MAX. SPL : 135 dB
• ANALOG OR DIGITAL : Analog
