Yamaha VXC5F VXC Series 4.5" Full Range Ceiling Speakers - White (Pair)

4.5" Full-range Ceiling Loudspeaker
Item ID: MB-VXC5FW-Pair
On Sale
or up to 12x interest-free Credit Card Installment payments of RM127.42 with max 24 months max 12 months More info

or up to 3 interest-free payments of RM509.67 with debit / credit card More info

Availability: Call For Status Check
Contacts Us To Check the Stock Status.

Estimated Shipping Fees - calculating...

Yamaha VXC5F VXC Series 4.5" Full Range Ceiling Speakers - White (Pair)

A versatile lineup for clear consistent sound

Yamaha designed the new VXC and VXS speakers to accommodate a growing list of applications in the installation market. While these speakers deliver quintessential Yamaha sound quality, they have also been carefully designed for safe and easy installation. Featuring both ceiling and surface mount options, these speaker series include a comprehensive range of models that are available in either black or white, or can be painted to match the interior of any application.

  • 4.5? full-range speaker unit
  • Engineered for optimum BGM reproduction
  • Wide coverage allows a single speaker to cover a wide area
  • Direct support for low-impedance or high-impedance connections
  • Low-profile design facilitates installation in limited ceiling spaces
  • Built-in carrying band increases safety during installation
  • Anti-drop tab mechanism provide secure temporary positioning during installation
  • Double-threaded speaker clamp screws for speedy tightening
  • Paintable grilles with magnetic catches
  • Black and white versions available
  • 3.1kg (6.8lbs)324 x D143 mm (12-13/16" x D5-11/16")

Speaker type Full rangeBass reflex
Frequency range (-10dB) 60 Hz - 20 kHz (Half-space:2)
Nominal coverage 130° conical (Half-space :2)
Components LF-HF 4.5? Full range unit
Power rating NOISE 40 W
PGM 80 W
PEAK 160 W
Nominal impedance 8
Transformer taps 100V 30 W15W7.5 W
70V 30 W15 W7.5 W3.8 W
SPL Sensitivity (1W; 1m on axis) 89 dB SPL (Half-space:2)
Peak (Calculated) 111 dB SPL (1mCalculated based on power rating and sensitivityexclusive of power compression)
I/O connectors Euroblock (4 pin) 1 (input: +/-loop-thru: +/-)
Protection circuit Load protection Full-range power limiting to protect network and transducers
Finish VXC5F: Black (approx. Munsell N3)VXC5FW: White (approx. Munsell N9.3)
Dimensions Diameter 324 mm (12-13/16")
D 143 mm (5-11/16")
Net weight 3.1 kg (6.8 lbs)
Cutout size 285 mm (11-1/4")
Required ceiling board thickness 5 mm - 37 mm
Accessories O-ringTile RailCutout TemplateEuro Block (4pin)Terminal Cover
Packaging Packaged in pairs
Certificate UL1480NFPA70CEEACRoHS
EN54-24 compliance -
Others Conduit tube: 15.4 mm - 21.3 mm
Dimension Packaging Weight : 8.0 kg
