Product Description
Yamaha VXL1B-8 Slim Line Array Loudspeaker with 8 x 1.5” Drivers - Black (VXL1B-8)
Yamaha VXL1B-8 Slim Line Array Loudspeaker with 8 x 1.5” Drivers - Black
VXL series line array speakers offer a unique combination of outstanding sound quality and slim form that is ideal for a variety of environments.
Line array speakers offer excellent projection as well as uniform volume and sound quality over a wide service area, making them a great choice for multipurpose halls, lecture halls, conference rooms, and other facilities that require maximum intelligibility throughout the listening area.
The VXL1 series includes three models with different numbers of speaker units. Models can be combined to optimally serve a variety of spaces and situations.
Slim 54-millimetre-wide cabinets and elegantly curved grille designs blend beautifully with any décor while delivering uniform, top-quality sound for speech and music reproduction in a wide range of applications.
FEATURES
- Slim line array speaker with 8 x 1.5" drivers.
- Finish: Black
- 1.5 inch (3.75 cm) full-range speaker unit with neodymium magnets
- Wide horizontal dispersion for uniform SPL over a wide area
- Slim design complements any interior décor
- Enclosures can be painted to match surroundings
- Wall mount bracket supplied
- Optional hardware for a wide range of installation needs
SPECIFICATIONS
| General specifications | VXL1B-24 / VXL1W-24 | VXL1B-16 / VXL1W-16 | VXL1B-8 / VXL1W-8 | |
|---|---|---|---|---|
| Speaker type | Full-range, Bass reflex | Full-range, Bass reflex | Full-range, Bass reflex | |
| Frequency range (-10dB) | 77 Hz - 20 kHz *1 | 81 Hz - 20 kHz *1 | 70 Hz - 20 kHz *1 | |
| Coverage area | Horizontal: 170°, Vertical:20°（ +10° - -10°） (NORMAL), 40°（+10° - -30°） (WIDE) | Horizontal: 170°, Vertical:20°（ +10° - -10°） (NORMAL), 40°（+10° - -30°） (WIDE) | Horizontal: 170°, Vertical:40°（+20° - -20°） | |
| Components | LF-HF | 1.5" (3.75 cm) Cone × 24 | 1.5" (3.75 cm) Cone × 16 | 1.5" (3.75 cm) Cone × 8 |
| Power rating | NOISE | 110 W | 80 W | 40 W |
| PGM | 220 W | 160 W | 80 W | |
| PEAK | 440 W | 320 W | 160 W | |
| Nominal impedance | 8Ω | 12Ω | 16Ω | |
| SPL | Sensitivity (1W; 1m on axis) | 91 dB SPL (1 m/1 W) *1 *2 | 91 dB SPL (1 m/1 W) *1 *2 | 89 dB SPL (1 m/1 W) *1 *2 |
| Peak (Calculated) | 117 dB SPL (1 m) *3 | 116 dB SPL (1 m) *3 | 111 dB SPL (1 m) *3 | |
| I/O connectors | Euroblock (2 pin) × 2 (input: +/-) Max. wire size AWG 12 (3.3 mm²) | Euroblock (2 pin) × 2 (input: +/-) Max. wire size AWG 12 (3.3 mm²) | Euroblock (2 pin) × 2 (input: +/-) Max. wire size AWG 12 (3.3 mm²) | |
| Protection circuit | Load protection | Full-range power limiting to protecting network and transducers | Full-range power limiting to protecting network and transducers | Full-range power limiting to protecting network and transducers |
| Finish | VXL1B-24: Black painting (approximate value: Munsell N3.0), VXL1W-24: White painting (approximate value: Munsell N9.0) | VXL1B-16: Black painting (approximate value: Munsell N3.0), VXL1W-16: White painting (approximate value: Munsell N9.0) | VXL1B-8: Black painting (approximate value: Munsell N3.0), VXL1W-8: White painting (approximate value: Munsell N9.0) | |
| Environmental | Dust and water resistant : IP35 | Dust and water resis tant : IP35 | Dust and water resistant : IP35 | |
| Packaging | Packaged in 1 pc | Packaged in 1 pc | Packaged in 1 pc | |
| Dimensions (W x H x D) | W54 × H1212 × D104 mm (Speaker only), W54 × H1212 × D111.5 mm (With included bracket) | W54 × H846 × D104 mm (Speaker only), W54 × H846 × D111.5 mm (With included bracket) | W54 × H480 × D104 mm (Speaker only), W54 × H480 × D111.5 mm (With included bracket) | |
| Weight | 5.5 kg (Speaker only) | 3.9 kg (Speaker only) | 2.1 kg (Speaker only) | |
