Yamaha MA2030A 2 Channel Compact Mixer Amplifier (MA-2030A)

Lo-Z/Hi-Z switchable Class-D mixer amplifier equipped with 3 types of selectable stereo inputs, 2 mic inputs and powerful DSP functions for high quality music playback and microphone use.
Item ID: MB-MA2030A
RM2,020.00
RM1,777.00
On Sale
Instant Savings: RM243.00 ( 0% GST)

Availability: Call For Status Check
Contacts Us To Check the Stock Status.
+6016-3111286

Estimated Shipping Fees - calculating...


Yamaha MA2030A 2 Channel Compact Mixer Amplifier (MA-2030A)


With quick, easy setup and intuitive operation, the compact MA and PA series power amplifiers make it easier than ever to bring your commercial space to life. The MA2030a and PA2030a are ideal audio solutions for retail stores, eateries, classrooms or public facilities like hospitals. The MA2120 and PA2120 meet the demands of a wide range of applications requiring higher power as well as more flexible DSP functionality and zone control. All models combine approachable, unobtrusive design with efficient, flexible performance. The MA2030a and MA2120 offer mixing capability with source EQ (Bass/Treble) control, as well as some of the same state-of-the-art DSP technol-ogies that are acclaimed features of professional Yamaha audio gear. Whether providing background music for a café or restaurant or powering a conference room or other application requiring microphone input, the MA/PA series amplifiers are simple yet powerful tools that can help establish an ideal commercial sound environment.
VIDEO

FEATURES
  • Easy setup, and a user-friendly interface for effortless operation
  • Supporting Lo-Z (30W @3Ω/4Ω/8Ω) and Hi-Z (60W x1ch, 70V/100V) speaker systems
  • Flexible 2 mic inputs and selectable 3 stereo inputs
  • Advanced DSP functions for music playback and microphone use (Feedback Suppressor, Priority Ducker, Leveler)
  • Bass and treble stereo source EQ with enhancer function
  • Built-in speaker EQ optimum for Yamaha VXC/VXS series speaker
  • Built-in HPF
  • Service zone can be expanded by adding a PA2030a
  • Remote volume control and microphone on/off switching via the optional DCP control panels (DCP1V4S, 1 DCP panel per unit)
  • Intelligent protection function ensures safe, reliable operation
  • Certified as Yamaha Eco Products

SPECIFICATIONS
General specifications MA2030a
Output power 1kHz (THD+N=1%: 3) 30W x 2 (20ms Burst)
1kHz (THD+N=1%: 4) 30W x 2 (20ms Burst)
1kHz (THD+N=1%: 8) 30W x 2 (20ms Burst)
High impedance: 100V line 60W x 1
High impedance: 70V line 60W x 1
Total harmonic distortion 0.1% (Stereo in to Speaker out @1kHzHalf power3/4/8)0.2% (Stereo in to Speaker out @1kHzHalf power70V/100V)
Frequency response 0dB-2.5dB+1.0dB (Stereo in to Line out20Hz to 20kHz)0dB-3.0dB+1.0dB (Stereo in to Speaker out50Hz to 20kHz1W3/4/8)0dB-3.0dB+1.0dB (Stereo in to Speaker out90Hz to 20kHz1W70V/100V)
Crosstalk -70dB (Stereo in to other Stereo in)
I/O Connectors Mic/Line Input -
Line Input -
Speaker Output Barrier strip x 2 pairs
Line Out Stereo RCA pin (unbalanced)
Control ports RJ-45 (for DCP1V4S)
Mic Input MIC IN 1: XLR combo jack (balanced)MIC IN 2: 3.5mm Euroblock (3-pinbalanced)
Stereo Input ST IN 1: Stereo mini phone (3.5mmunbalanced)ST IN 2 / ST IN 3: Stereo RCA pin (unbalanced)
Input Level Mic input: -76 dBu (Sensitivity)-66 dBu (Nominal)-22 dBu (Max before clip) / Line input: -10dBV (Sensitivity)-10dBV (Nominal)+10dBV (Max before clip)
Output Level -10dBV (LINE OUTNominal)
Processors Speaker EQ (VXS:Full RangeVXC)HPF (150Hz)
Protection circuit Load protection Power switch on/off: Mute the output*Output voltage protection: Compress the output*DC-fault: Power supply shutdown (*Restored automatically)
Amplifier protection Thermal: Limit the output*   Mute*   ShutdownOver current: Mute the output*Integrated power limit: Compress the output* (*Restored automatically)
Power supply protection Thermal: Power supply shutdownOver voltage: Power supply shutdownOver current: Power supply shutdown
Amplifier class Class D
Cooling Conventional coolingbottom to up airflow
Power requirements 100V120V230V-240V; 50Hz/60Hz
Power consumption 30W (1/8max. power3AC 100Vpink noise at all channels)
Dimensions W 215mm (8.5?) *1
H 54mm (2.1?) *1
D 288mm (11.4?) *1
Net weight 1.8kg (4.0lbs)
Accessories AC power cable3.5mm Euroblock plug (3-pin) x 1Owners manualSpecification sheet
Options RKH1 (Rack-mount Accessory)DCP1V4S (Digital Control Panel)
Certificate -
Others Operating Temperature: 0°C to + 40°CStorage Temperature: -20°C to + 60°CRack-mountable when ensuring sufficient ventilation above and below the unit
