Zoom LiveTrak L12next Digital Mixer-Recorders

Combining the power of a digital mixer with an analog-style workflow, the Zoom LiveTrak L12Next puts you in total control, enabling you to mix with speed and confidence. Each of the LiveTrak L12Next’s 12 channels brandishes a high-quality 60mm fader and three multifunction encoders, providing you with hands-on access to gain, EQ, compression, panning, and sends. Additionally, its comprehensive I/O, which includes eight upgraded preamps, accommodates everything from a solo performer to a small band. Moreover, the LiveTrak L12Next’s onboard recorder effortlessly captures 14 individual tracks in stunning 24-bit/96kHz quality, bolstered by a 32-bit float master channel for clip-free results. You’ll love what this miniature mixer’s onboard DSP does for your mixes, granting you instant access to 16 ear-grabbing effects using two intuitive parameter controls. You also get Overdub Mode and Auto Punch In/Out features for straightforward layering and re-recording, custom recall of 10 scenes, five independent Monitor Outs, and a built-in Talkback function. This digital mixer also features a 14-in/4-out USB audio interface with DAW control and seamless integration with streaming software.

FEATURES

• A compact 12-ch. digital mixer with the features you'd expect from a full-size mixer

• High-quality 60mm faders and multifunction encoders grant hands-on access to gain, EQ, compression, panning, and sends

• 8 upgraded, low-noise preamps with 70dB of clean gain and a hi-Z input, a Pad switch, and +48V phantom power

• Enough I/O to accommodate everything from a solo performer to a small band

• Onboard recorder effortlessly captures 14 individual tracks in stunning 24-bit/96kHz quality

• 32-bit float master channel delivers pristine, clip-free results
• Master Compressor adds warm, natural dynamics control that glues your mix together

• 16 onboard FX accessed via 2 easily accessible parameter controls

• Overdub Mode and Auto Punch In/Out allow for precise layering and easy re-recording

• File Select button lets you load additional tracks to expand your mix

• Stores up to 10 scene memories, saving fader positions, EQ, pan, mutes, FX, and more for easy recall
  14-in/4-out USB audio interface provides streamlined recording to your computer or mobile device

• Simultaneous recording to your DAW and an SD card

SPECIFICATIONS

• Type : Digital Mixer

• Channels : 12

• Inputs - Mic Preamps : 8 x XLR-1/4" Combo

• Phantom Power : 8 Channels (1-4, 5-8)

• Inputs - Line : 4 x 1/4" TRS (9/10, 11/12)

• Inputs - Other : 1 x 1/4" (control)

• Outputs - Main : 2 x XLR

• Send/Return I/O : 4 x 1/4" TRS (monitor sends)

• Headphones : 1 x 1/4"

• USB : 1 x USB-C

• Computer Connectivity : USB (14 x 4)

• Faders : 12 x 60mm

• A/D Resolution :24-bit/96kHz

• EQ Bands : 3-band, Sweepable Mid

• Effects : Yes

• Signal Processing : Compressor

• Transport Controls : Yes

• DAW Control : Yes

• Power Source : 12V DC

• Height: 2.87"

• Depth: 11.22"

• Width: 17.51"

• Weight: 5.29 lbs.
