B-STOCK (BS-256) M-Audio BX5 D3 5 inch Powered Studio Monitor (Unit)

The BX5 D3 was meticulously engineered to provide accurate sound reproduction. A high-current, high-headroom Class A/B amplifier drives a 5" military-grade Kevlar woofer and 1" silk dome tweeter. The speaker features a bi-amplified design, so it exhibits a sound that's both powerful and precise. A rear-mounted port was built to a specific length and diameter to produce deep, defined bass. A custom waveguide eliminates unwanted high-frequency scatter, ensuring that the BX5 D3's imaging is spot on. And don't worry about positioning — a front-panel LED shines brightly when the BX5 D3 is at the ideal monitor angle.

FEATURES

• Bi-amplified design with 100 watts (60 LF, 40 HF) for powerful, accurate sound

• 5” Kevlar low-frequency driver with high-temp voice coil and damped rubber surround

• 1” natural silk dome tweeter delivers superb transient details

• New computer-optimized tweeter waveguide for precise imaging

• Acoustic Space Control to fine-tune low-end response to your room

• Optimized rear port for extended low-frequency response

• XLR balanced and 1/4” balanced/unbalanced inputs for connecting audio interfaces, mixers, synthesizers, DJ gear, and more

• Volume control enables you to dial in the perfect monitor playback level

• Ultra-wide range 52-35kHz frequency response covers full musical spectrum

• Front panel LED shines brightly when speaker is positioned at ideal monitor angle

SPECIFICATIONS

• TYPE 2-way near-field studio reference monitors

• LOW FREQ. DRIVER : 5 inch (127mm) Kevlar curved cone with high temperature voice coil and damped rubber surround. Magnetically shielded

• HIGH FREQ. DRIVER : 1 inch (25mm) magnetically shielded natural silk dome

• FREQUENCY RESPONSE : 52 Hz – 35 kHz

• CROSSOVER FREQUENCY : 2.5kHz

• LOW FREQ. AMPLIFIER POWER : 60W

• HIGH FREQ. AMPLIFIER POWER : 40W

• MAXIMUM PEAK SPL : 110 dB SPL - Full Bandwidth Pink Noise Measured

• INPUT SENSITIVITY : -10dBU

• INPUT CONNECTORS : 1x XLR balanced input connector 1x TRS balanced/unbalanced input connector

• INPUT IMPEDANCE : 10kΩ balanced, 20kΩ unbalanced

• POLARITY : Positive signal at + input produce outward LF cone displacement

• PROTECTION : RF interference, output current limiting, over temperature, turn on/off transient, subsonic filter, external mains fuse

• POWER : Voltage: 100–120V, 50/60 Hz / 220–240V, 50/60 Hz Consumption: 100W

• FUSE : 220–240V~ T1AL 250V / 100–120V~ T1.6AL 250V

• CABINET : Vinyl-laminated high-acoustic-efficiency MDF

• DIMENSIONS(WIDTH X DEPTH X HEIGHT) : 6.9” x 7.8” x 10” / 176 x 197 x 254 mm

• WEIGHT : 12.3 lbs, 5.6kg
