PA Sound System Setup for Small Mosque (PA System untuk Masjid Kecil, Sound System untuk Surau Kecil), TOA A-2240D Mixer Amp, TOA TZ-406B Column Speaker System and TH652 Horn Speakers with Shure SV200 Wired Microphone (A2240D / TZ406)

FEATURES

• 1 x TOA A-2240D Digital Mixer Power Amplifier
• 4 x TOA TZ-406B 40W Column Speaker System - Black
• 2 x TOA Horn Speaker TH-652 (TH652)
• 2 x TOA TU-652M 50W Driver Unit
• 1 x Shure SV200 Dynamic Vocal Microphone with XLR to QTR Cable (6.3 mm)

SPECIFICATIONS

TOA A-2240D Digital Mixer Power Amplifier

• Power Source : 220 - 240 V, 50/60Hz
• Rated Output : 240 W
• Power Consumption : 48 W (AC operation at 1/8 maximum output without clip)
• Frequency Response : 50 - 20,000 Hz, ±3 dB
• Distortion : Under 1% at 1 kHz, 1/3 rated power
• Input : MIC 1-3: -60 dB*, 600 Ω, balanced, 3P XLR
• AUX 1-2: -20 dB*, 10 kΩ, unbalanced, RCA pin jack
• Output : Speaker out: Balanced (floating)
• High impedance: 42 Ω (100 V)
• Rec out: 0 dB*, 600 Ω, unbalanced, RCA pin jack
• Phantom Power : DC +21 V (MIC 1)
• S/N Ratio : Over 60 dB
• Tone Control : Bass: ±10 dB at 100 Hz
• Treble: ±10 dB at 10 kHz
• Muting : MIC 1: Mutes other input signals by 0-30 dB attenuation
• Indicator : Power LED, peak LED, signal LED
• Finish : Panel: ABS resin, black
• Case: Steel plate, black
• Dimensions : 420 (W) × 100.6 (H) × 280.3 (D) mm (16.54" × 3.96" × 11.04")
• Weight : 4.0 kg (8.88 lb)

TOA TZ-406B Column Speaker System :

• Enclosure : Sealed Type
• Rated Input : 40 W
• Rated Impedance : 100 V line: 250 Ω (40 W), 500 Ω (20 W), 1 kΩ (10 W), 2 kΩ (5 W)
• 70 V line: 250 Ω (20 W), 500 Ω (10 W), 1 kΩ (5 W), 2 kΩ (2.5 W)
• Sensitivity : 93 dB (1 W, 1 m)
• Frequency Response : 150 Hz - 16,000 Hz
• Speaker Component : 10 cm cone-type × 4
• Input Terminal : Push-In terminal
• Finish : Enclosure: HIPS, black, paint
  Punched Net: Surface-tread steel plate, black, paint
  Speaker Bracket: Aluminum die-cast, black, paint
  Joint Bracket, Wall Bracket: Steel plate, t1.6, black, paint
• Dimensions : 135 (W) × 498 (H) × 128 (D) mm
• Weight : 3.5 kg (unit only)

TOA Horn Speaker TH-652 (TH652) :

• Applicable Drivers : TU-632, TU-632M, TU-652, TU-652M
• Sound Pressure Level : 110 dB (1 W, 1 m) (When operated with a driver.)
• Frequency Response : 200 Hz - 6,000 Hz (When operated with a driver.)
• Dust/Water Protection : IP65 (When operated with a driver.)
• Driver Coupling : 1 - 3/8 18 threads (inch screw)
• Operating Temperature : -20 °C to +55 °C (must be free from dew condensation)
• Finish : Horn flare and flange: Aluminum, White, powder coating
• Reflector horn: HIPS, White
• Bracket: Steel, White, powder coating
• Screws and bolts: Stainless steel
• Dimensions : Φ500 × 357 (D) mm
• Weight : 2.7 kg

TOA TU-652M 50W Driver Unit :

• Applicable Horns : TH-652
• Rated Input : 50 W
• Line Voltage : 100 V line or 70 V line
• Rated Impedance : 100 V line: 200 Ω (50 W), 330 Ω (30 W), 670 Ω (15 W)
• 70 V line: 100 Ω (50 W), 200 Ω (25 W), 330 Ω (15 W), 670 Ω (7.5 W)
• Output Sound Pressure Level : 110 dB (1 W, 1 m) (When operated with JIS C 5504 standard horn.)
• Frequency Response : 150 Hz - 6,000 Hz (When operated with JIS C 5504 standard horn.)
• IP Code : IP65 (When a driver is operated with a horn.)
• Horn Coupling : 1 - 3/8 18 threads (inch screw)
• Polarity : Hot: Black, Com: White
• Operating Temperature : -20°C to +55°C (-4°F to +131°F) (must be free from dew condensation)
• Finish : Upper Cover: Aluminum, White, powder coating
• Unit Case: HIPS. White
• Screws: Stainless steel
• Speaker cable: Polyvinyl chloride insulated cabtyre cable
• (6 mm (0.24") in diameter, 450 mm (17.72") in length), White
• Dimensions : Φ139 × 149 (D) mm (Φ5.47" × 5.87")
• Weight : 2.7 kg (5.95 lb)

Shure SV200 Dynamic Vocal Microphone with XLR to QTR Cable (6.3 mm) :

• Cardioid Polar Pattern
• On/Off Switch
• Includes 15ft XLR to QTR Cable
